The image displays a gray plastic tray with many small compartments. It has a rectangular shape with forty recessed areas to neatly organize objects.
Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD
(Product No.: 032.T-242)
The image displays a gray plastic tray with many small compartments. It has a rectangular shape with forty recessed areas to neatly organize objects.
Notice / Inquire

Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD

dpvlink:
18918
Length :
553 mm
Width :
353 mm
Height :
40 mm
Properties:
Further product information
Imprinting / Printing for boxes
Configure now


Minimum order:
10 PCE
Delivery time! Delivery time!
18,55 EUR

excl. 19% tax

10 PCE
Compare Compare
Notice / Inquire
Product Info

Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD

The deep-drawing insert T-242 from Licefa is a highly functional solution for the safe storage and transport of sensitive electronic components. With dimensions of 553 x 353 x 40 mm and a total of 27 compartments, each measuring 107 x 47 x 22 mm, this product is specifically designed for containers sized 600 x 400 mm.
The insert is characterized by its electrical conductivity, which is standardized according to DIN EN 61340-5-1, with a surface resistance between 10^3 and 10^5 Ohm. This feature makes it ideal for use in ESD-sensitive environments to prevent static discharges.
Additionally, the deep-drawing insert offers practical features such as a recessed grip and the option for reversible stacking, which simplifies handling and storage. The robust construction from conductive plastic (Liastat) ensures durability and protection of the stored components.
Length
Length
553 mm
Width
Width
353 mm
Height
Height
40 mm
Conductivity
Conductivity
conductive
Surface resistance Rs
Surface resistance Rs
103 - 105 Ω
Cavities
Cavities
27
Dimensions cavities
Dimensions cavities
107x47x22 mm
Suitable for containers
Suitable for containers
600x400 mm
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 317
Complete Catalog 2023 - 2024
Configurators:
Imprinting / Printing for boxes

Product Family

Vacuum-formed inserts T-242

Article image
Article description
Length
Width
Height
Price
Compare
032.T-242 - Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD
032.T-242
Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD
553 mm
353 mm
40 mm
18,55 EUR
