The image shows a rectangular, gray plastic mold with 28 small square indentations. It has an elongated side and measures 355 mm x 253 mm.
Vacuum-formed insert T-230 355 x 253 x 21 mm, 35 compartments
(Product No.: 032.T-230)
The image shows a rectangular, gray plastic mold with 28 small square indentations. It has an elongated side and measures 355 mm x 253 mm.
Notice / Inquire

Vacuum-formed insert T-230 355 x 253 x 21 mm, 35 compartments

dpvlink:
18900
Length :
355 mm
Width :
253 mm
Height :
21 mm
Properties:
Further product information

Imprinting / Printing for boxes

Minimum order:
10 PCE
available available
 Configurable
9,85 EUR
per PCE

excl. 19% tax

10 PCE
Compare Compare
Notice / Inquire
Product Info

Vacuum-formed insert T-230 355 x 253 x 21 mm, 35 compartments

The deep-drawing insert T-230 from Licefa, with dimensions of 355 x 253 x 21 mm, is specially designed for the storage and transport of electrostatically sensitive components. This insert is made from electrically conductive plastic and complies with the standard DIN EN 61340-5-1, which allows for controlled dissipation of electrostatic charges and minimizes the risk of damage to electronic components.
The insert has 35 compartments, each measuring 35x35x15 mm, and is ideal for containers sized 400x300 mm. The integrated handle facilitates handling. The surface resistance is between ≥ 10^4 and < 10^11 Ω, making it particularly effective in preventing uncontrolled discharges. Additionally, the insert is designed for continuous use at temperatures from -10 to 80 °C.
These deep-drawing inserts offer structured and standard-compliant storage and are an excellent choice for secure internal transport within electrostatically protected areas.
Length
Length
355 mm
Width
Width
253 mm
Height
Height
21 mm
Conductivity
Conductivity
dissipative
Surface resistance Rs
Surface resistance Rs
≥ 104 - < 1011 Ω
Cavities
Cavities
35
Dimensions cavities
Dimensions cavities
35x35x15 mm
Suitable for containers
Suitable for containers
400x300 mm
Continuous use temperature
Continuous use temperature
-10-80 °C
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

For this article you will find, for example, (operating) instructions, product and material information, care instructions, safety and technical data sheets. Please log in or register now to access the documents.

Login or register now
