Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD
Vacuum-formed insert T-242 553 x 353 x 40 mm, 27 compartments ESD
The deep-drawing insert T-242 from Licefa is a highly functional solution for the safe storage and transport of sensitive electronic components. With dimensions of 553 x 353 x 40 mm and a total of 27 compartments, each measuring 107 x 47 x 22 mm, this product is specifically designed for containers sized 600 x 400 mm.The insert is characterized by its electrical conductivity, which is standardized according to DIN EN 61340-5-1, with a surface resistance between 10^3 and 10^5 Ohm. This feature makes it ideal for use in ESD-sensitive environments to prevent static discharges.
Additionally, the deep-drawing insert offers practical features such as a recessed grip and the option for reversible stacking, which simplifies handling and storage. The robust construction from conductive plastic (Liastat) ensures durability and protection of the stored components.
Details
- Length Length
- 553 mm
- Width Width
- 353 mm
- Height Height
- 40 mm
- Conductivity Conductivity
- conductive
- Surface resistance Rs Surface resistance Rs
- 103 - 105 Ω
- Cavities Cavities
- 27
- Dimensions cavities Dimensions cavities
- 107x47x22 mm
- Suitable for containers Suitable for containers
- 600x400 mm
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.
