The image displays a gray plastic plate with many small round indentations. It is rectangular, measuring 553 mm in length and 353 mm in width, with a height of 42 mm.
Vacuum-formed insert T-249 553 x 353 x 36 mm, 70 compartments ESD
(Product No.: 032.T-249)
The image displays a gray plastic plate with many small round indentations. It is rectangular, measuring 553 mm in length and 353 mm in width, with a height of 42 mm.

Vacuum-formed insert T-249 553 x 353 x 36 mm, 70 compartments ESD

dpvlink:
19000
Length :
553 mm
Width :
353 mm
Height :
36 mm
Properties:
Further product information
Imprinting / Printing for boxes
Configure now


Delivery time! Delivery time!

Compare Compare
Notice / Inquire
Product Info

Vacuum-formed insert T-249 553 x 353 x 36 mm, 70 compartments ESD

The deep-drawing insert T-249 from Licefa, with dimensions of 553 x 353 x 36 mm, is specifically designed for the secure storage and transport of sensitive electronic components. This insert features 70 compartments with a diameter of 42x32 mm each, made from electrically conductive material and complying with the standards of DIN EN 61340-5-1. The conductivity of the material ensures a surface resistance between 10^3 and 10^5 Ohm, providing protection against electrostatic discharges.
The insert is also suitable for containers sized 600x400 mm and offers comfortable handling through reversible stacking and a practical handle recess. The minimum order quantity is 50 pieces. With these technical features, the deep-drawing insert T-249 is ideally suited for technical purchasers looking for high-quality solutions for ESD-safe storage.
Length
Length
553 mm
Width
Width
353 mm
Height
Height
36 mm
Conductivity
Conductivity
conductive
Surface resistance Rs
Surface resistance Rs
103 - 105 Ω
Cavities
Cavities
70
Dimensions cavities
Dimensions cavities
42x32 mm
Suitable for containers
Suitable for containers
600x400 mm
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 321
Complete Catalog 2023 - 2024
