Soft PVC film 200 mm
(Product No.: 5715.02.200.50)
The image shows a roll of transparent film. The film is light and shiny, while the roll core and the edge are dark blue. A piece of the film extends from the roll core.
A person in a white protective suit and mask is working at a table. They are opening a purple box. The room appears sterile, with bright lighting and transparent curtains.
Mobile Preview: The image shows a roll of transparent film. The film is light and shiny, while the roll core and the edge are dark blue. A piece of the film extends from the roll core.
Mobile Preview: A person in a white protective suit and mask is working at a table. They are opening a purple box. The room appears sterile, with bright lighting and transparent curtains.

Soft PVC film 200 mm

dpvlink:
26129
Properties:
Further product information

chevron-down
available available

Compare Compare
Notice / Inquire
Product Info

Soft PVC film 200 mm

The soft PVC film, with a roll width of 200 mm and a length of 50 meters, offers a total area of 10 m². The film provides a light transmittance of over 80%. It meets the ESD standard DIN EN 61340-5-1, making it ideal for applications in ESD areas. It is ideally suited as a strip curtain or as a viewing window.
The film is permanently electrostatically dissipative, with resistance values between < 1 x 10^4 to < 1 x 10^11 Ohm.

Color
Color
blue / transparent
Length
Length
5000 mm
Roll length
Roll length
50 m
Thickness
Thickness
2 mm
Width
Width
200 mm
Surface resistance Rs
Surface resistance Rs
< 1 x 104 - < 1 x 1011 Ω
Volume resistance
Volume resistance
< 1 x 104 - < 1 x 1011 Ω
ESD
ESD
yes
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 171
Complete Catalog 2023 - 2024

Product Family

PVC film

Soft PVC film

  • Permanently dissipative PVC film
  • Volume dissipative
  • Roll length 50m
  • Film width 200 or 300 mm
  • Film thickness 2 mm
  • Transculent (transparency ≥ 80%)

In compliance with the ESD standard DIN EN 61340-5-1


Article image
Article description
ESD
Color
Length
Roll length
Thickness
Width
Surface resistance Rs
Volume resistance
ESD
Price
Compare
5715.02.200.50 - Soft PVC film 200 mm
5715.02.200.50
Soft PVC film 200 mm
blue / transparent
5000 mm
50 m
2 mm
200 mm
< 1 x 104 - < 1 x 1011 Ω
< 1 x 104 - < 1 x 1011 Ω
yes
-
5715.02.300.50 - Soft PVC film 300 mm
5715.02.300.50
Soft PVC film 300 mm
blue / transparent
5000 mm
50 m
2 mm
300 mm
< 1 x 104 - < 1 x 1011 Ω
< 1 x 104 - < 1 x 1011 Ω
yes
-
