The image depicts a slender, metallic pen that has black, fringed fibers at one end. The pen is smooth and shiny, while the fibers are soft and uneven.
ESD Nylon brush, 3 mm
(Product No.: 6103.B.200)
The image depicts a slender, metallic pen that has black, fringed fibers at one end. The pen is smooth and shiny, while the fibers are soft and uneven.
Notice / Inquire

ESD Nylon brush, 3 mm

dpvlink:
8613
Hardness:
hard
Width :
3.0 mm
Brush length:
13 mm
Bristle color:
black
Properties:
Further product information

chevron-down
available available
9,05 EUR

excl. 19% tax

1 PCE
Compare Compare
Notice / Inquire
Product Info

ESD Nylon brush, 3 mm

The ESD brush, with a width of 3 mm and a bristle length of 13 mm, is specifically designed for cleaning ESD-sensitive flat assemblies. The high-quality, black nylon bristles are electrically conductive and prevent the formation of static charges during cleaning tasks. The handle made from volume conductive plastic is marked with an ESD warning symbol and ensures additional safety. The bristles of the brush have a diameter of 0.4 mm and are embedded in the plastic handle to ensure permanent conductivity. The discharge resistance of the brush is between 10^4 and 10^5 Ohms, which meets the requirements of the ESD standard DIN EN 61340-5-1. This makes the ESD brush an indispensable tool for all technical areas where electrostatic discharges pose a risk.
Hardness
Hardness
hard
Width
Width
3.0 mm
Brush length
Brush length
13 mm
Bristle color
Bristle color
black
Bleeder resistance
Bleeder resistance
104 - 105 Ω
Bristles
Bristles
nylon bristles / dissipative
ESD
ESD
yes
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 172
Complete Catalog 2023 - 2024

Product Family

ESD Nylon brush, black

When using these conductive brushes, cleaning work does not cause static charges on ESD-sensitive flat assemblies.

  • Integrated, permanently dissipative nylon bristles
  • Volume-conductive plastic handle with ESD warning symbol
  • Bristle diameter 0.4 mm

In compliance with the ESD standard DIN EN 61340-5-1


Article image
Article description
ESD
Hardness
Width
Brush length
Bristle color
Price
Compare
6103.B.200 - ESD Nylon brush, 3 mm
6103.B.200
ESD Nylon brush, 3 mm
hard
3.0 mm
13 mm
black
9,05 EUR
6103.B.201 - ESD Nylon brush, 6 mm
6103.B.201
ESD Nylon brush, 6 mm
hard
6 mm
16 mm
black
8,40 EUR
